Magnetothermal Switch 1P+N 6kA Curve C MAXGE Alpha+

MAXGE Alpha+ Residential Magnetothermal Switch: Advanced Protection for Electrical Installations

The MAXGE Residential Magnetothermal Switch, model Alpha+, is an essential protection device designed to ensure safety in residential electrical installations. With a capacity to interrupt currents of up to 6 kA and a nominal voltage of 230-400V AC, this switch is suitable for a wide range of domestic applications. The availability in different current intensities (10, 16, 20, 25, 32 and 40 A) makes it adaptable to various energy needs, while the type C trip curve ensures effective protection against overloads and short circuits.

Features and Technical Specifications

• Cutting Power : 6 kA, offering reliable protection in the event of overload or short circuit conditions.
• Nominal Voltage : Operates in a range of 230-400V AC, compatible with most residential installations.
• Frequency : Designed for 50-60 Hz systems, adapting to international standards.
• Trip Curve : Type C, ideal for inductive and resistive loads in the residential environment.
• Indoor Use with IP20 Protection : Ensures safe operation in dry indoor environments.
• Material : Made of PC and ABS, strong and durable materials.
• Dimensions and Weight : Compact, with a width and height of 36 mm and a weight of 180 g, facilitating its installation in electrical panels.
• Working Temperature : Capable of operating in a wide range of ambient temperatures, from -25°C to +55°C.
• Number of Poles : 1P + N, providing protection in both phase and neutral.
• 3 Year Guarantee : Quality and reliability support from MAXGE.
• Certifications : Complies with CE & RoHS, UKCA, and international standard EN/IEC60898-1.

Advantages and benefits

• Flexibility : Wide range of intensities available to adapt to different energy needs.
• Easy Connection : Cable connection capacity up to 35 mm² and compatibility with pin and fork type connection combs.
• Local Status Signaling : Facilitates quick identification of the operating status of the switch.
• Circuit Marker Window : Allows easy identification and organization of protected circuits.

The MAXGE Alpha+ Residential Magnetothermal Switch represents an advanced solution for the protection of electrical installations in the home, office or business, combining high quality, safety and versatility. With its modern design, advanced technical specifications and compliance with international regulations, this magneto-thermal switch is an excellent choice for those seeking maximum safety and reliability in their electrical system.
